B-80 G30 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F173
ENUMERATION: DCmA INPUT/OUTPUT RANGE
F174
ENUMERATION: TRANSDUCER RTD INPUT TYPE
0 = 100 Ohm Platinum, 1 = 120 Ohm Nickel,
2 = 100 Ohm Nickel, 3 = 10 Ohm Copper
F176
ENUMERATION: SYNCHROCHECK DEAD SOURCE SELECT
F177
ENUMERATION: COMMUNICATION PORT
0 = None, 1 = COM1-RS485 (not applicable to UR firmware 7.00),
2 = COM2-RS485, 3 = Front Panel-RS232, 4 = Network - TCP,
5 = Network - UDP
F179
ENUMERATION: NEGATIVE SEQUENCE DIRECTIONAL
OVERCURRENT TYPE
0 = Neg Sequence, 1 = Zero Sequence
F183
ENUMERATION: AC INPUT WAVEFORMS
F184
ENUMERATION: IEC GOOSE DATASET
F186
ENUMERATION: MEASUREMENT MODE
0 = Phase to Ground, 1 = Phase to Phase
F189
ENUMERATION: INRUSH INHIBIT MODE
0 = Per Phase, 1 = 2-out-of-3, 2 = Average
F190
ENUMERATION: SIMULATED KEYPRESS
Bitmask DCmA input/output range
0 0 to –1 mA
1 0 to 1 mA
2 –1 to 1 mA
3 0 to 5 mA
4 0 to 10 mA
5 0 to 20 mA
6 4 to 20 mA
Bitmask Synchrocheck dead source
0None
1 LV1 and DV2
2 DV1 and LV2
3 DV1 or DV2
4DV1 Xor DV2
5 DV1 and DV2
Bitmask Definition
0Off
1 8 samples/cycle
2 16 samples/cycle
3 32 samples/cycle
4 64 samples/cycle
Value IEC 61850 dataset
0Off
1 GooseIn 1
2 GooseIn 2
3 GooseIn 3
4 GooseIn 4
5 GooseIn 5
6 GooseIn 6
7 GooseIn 7
8 GooseIn 8
9 GooseIn 9
10 GooseIn 10
11 GooseIn 11
12 GooseIn 12
13 GooseIn 13
14 GooseIn 14
15 GooseIn 15
16 GooseIn 16
Bitmask Keypress Bitmask Keypress
0 No key ---
use between real keys
23 Reset
24 User 1
1 1 25 User 2
2 2 26 User 3
3 3 27 User-programmable key 1
4 4 28 User-programmable key 2
5 5 29 User-programmable key 3
6 6 30 User-programmable key 4
7 7 31 User-programmable key 5
8 8 32 User-programmable key 6
9 9 33 User-programmable key 7
10 0 34 User-programmable key 8
11 Decimal Point 35 User-programmable key 9
12 Plus/Minus 36 User-programmable key 10
13 Value Up 37 User-programmable key 11
14 Value Down 38 User-programmable key 12
15 Message Up 39 User 4 (control pushbutton)
16 Message Down 40 User 5 (control pushbutton)
