GE Multilin G30 Generator Protection System B-81
APPENDIX B B.4 MEMORY MAPPING
B
F192
ENUMERATION: ETHERNET OPERATION MODE
0 = Half-Duplex, 1 = Full-Duplex
F193
ENUMERATION: ACCIDENTAL ENERG. ARMING MODE
0 = UV and Offline, 1 = UV or Offline
F194
ENUMERATION: DNP SCALE
0 = 0.01, 1 = 0.1, 2 = 1, 3 = 10, 4 = 100, 5 = 1000, 6 = 10000,
7 = 100000, 8 = 0.001
F196
ENUMERATION: NEUTRAL DIRECTIONAL OVERCURRENT
OPERATING CURRENT
0 = Calculated 3I0, 1 = Measured IG
F200
TEXT40: 40-CHARACTER ASCII TEXT
20 registers, 16 Bits: 1st Char MSB, 2nd Char LSB
F202
TEXT20: 20-CHARACTER ASCII TEXT
10 registers, 16 Bits: 1st Char MSB, 2nd Char LSB
F203
TEXT16: 16-CHARACTER ASCII TEXT
F204
TEXT80: 80-CHARACTER ASCII TEXT
F205
TEXT12: 12-CHARACTER ASCII TEXT
F206
TEXT6: 6-CHARACTER ASCII TEXT
F207
TEXT4: 4-CHARACTER ASCII TEXT
F209
TEXT65: 65-CHARACTER ASCII TEXT
F213
TEXT32: 32-CHARACTER ASCII TEXT
F220
ENUMERATION: PUSHBUTTON MESSAGE PRIORITY
F224
ENUMERATION: RATE TREND FOR FREQ RATE OF CHANGE
0 = Increasing, 1 = Decreasing, 2 = Bidirectional
F225
ENUMERATION: SPLIT PHASE PROTECTION MODE
0 = Over, 1 = Over-Under
F230
ENUMERATION: DIRECTIONAL POLARIZING
0 = Voltage, 1 = Current, 2 = Dual, 3 = Dual-V, 4 = Dual-I
F231
ENUMERATION: POLARIZING VOLTAGE
0 = Calculated V0, 1 = Measured VX
F232
ENUMERATION: CONFIGURABLE GOOSE Tx
DATASET ITEMS
17 Message Left 41 User 6 (control pushbutton)
18 Message Right 42 User 7 (control pushbutton)
19 Menu 43 User-programmable key 13
20 Help 44 User-programmable key 14
21 Escape 45 User-programmable key 15
22 Enter 46 User-programmable key 16
Bitmask Keypress Bitmask Keypress
Value Priority
0 Disabled
1Normal
2 High Priority
Value IEC 61850 Tx dataset item
0None
1 GGIO1.ST.Ind1.q
2 GGIO1.ST.Ind1.stVal
3 GGIO1.ST.Ind2.q
4 GGIO1.ST.Ind2.stVal
↓↓
255 GGIO1.ST.Ind128.q
256 GGIO1.ST.Ind128.stVal
257 MMXU1.MX.TotW.mag.f
258 MMXU1.MX.TotVAr.mag.f
259 MMXU1.MX.TotVA.mag.f
260 MMXU1.MX.TotPF.mag.f
261 MMXU1.MX.Hz.mag.f
262 MMXU1.MX.PPV.phsAB.cVal.mag.f
263 MMXU1.MX.PPV.phsAB.cVal.ang.f
