GE GEP - Connecting the DC Input Cable

Electrical Connection
18
User Manual V1.3-2022-11-18
NOTICE
6HDOWKH39LQSXWWHUPLQDOVXVLQJZDWHUSURRIFRYHUVZKHQWKH\DUHQRWWREHXVHG2WKHUZLVH
WKHLQJUHVVSURWHFWLRQUDWLQJZLOOEHLQࢊXHQFHG
Click
Step 1 Prepare DC cables.
Step 2 Crimp the crimp contacts.
Step 3 Disassemble the PV connectors.
Step 40DNHWKH'&FDEOHDQGGHWHFWWKH'&LQSXWYROWDJH
Step 5 Plug the PV connectors into the PV terminals.
Connecting the DC Input Cable
Devalan PV connector
