GE GFE26JSM User Manual

– 11 –
Specications
NO LOAD PERFORMANCE
CONTROL POSITION 0 / 37°F and
AMBIENT TEMPERATURE OF
65°F 90°F
Fresh Food, °F
38 - 40 36 - 38
Frozen Food, °F
0 - 1 0 - 2
Percent Running Time
25 - 50 50 - 80
REFRIGERATION DIAGNOSIS
To access the low pressure side of the system,
install a WJ56X61 valve only on the process
tube extending from the compressor case.
REFRIGERATION SYSTEM
Minimum Equalized Pressure
@ 70°F 40/45 PSIG
@ 90°F 48/60 PSIG
R134a Refrig. Chg.
18 cu. ft. models:
24 cu. ft. models:
26 cu. ft. models:
4.00 ounces
4.25 ounces
4.48 ounces
Electrical Shock Hazard
Death or serious injury can result from failure
to follow these instructions.
• Service by a qualied service technician
only.
• Disconnect power before servicing this
product.
• Reconnect all grounding devices after
service.
• Replace all parts and panels before
operating.
WARNING
ELECTRICAL SPECIFICATIONS
Max Defrost Control
w/No Door Openings 96 hrs @ 40 min
Evap Defrost Thermostat
Defrost Heater
Fill Tube Heater
Mullion Heater
Recess Heater
Duct Door Heater
Duct Door Motor
Damper Motor
Isolation Valve
Icemaker Valve
Dispenser Valve
Compressor Windings
Ice Blower Fan
Evaporator Fan
Condenser Fan
Auger Motor
Icemaker
95 - 65°F
120 VAC / 33
Ω
13 VDC / 136Ω
13 VDC / 24Ω
13 VDC / 100Ω
120 VAC / 1100Ω
13 VDC / 15Ω
415Ω
120 VAC / 320Ω
120 VAC / 320Ω
120 VAC / 120Ω
120 VAC / 4Ω & 6Ω
6-13 VDC
8-11 VDC
9-10 VDC
120 VAC
120 VAC

GE GFE26JSM Specifications

General

Brand	GE
Model	GFE26JSM
Category	Refrigerator
Language	English
