– 41 –
3. Remove two T20 Torx-head screws.
4. Pull the door stop and bushing out of the door.
5. The bushing is keyed, turn the bushing to
align the tabs of the bushing with the slots in
the door stop.
6. Pull the bushing out of the door stop.
NOTE: Like the door stop, the door is also keyed.
Once a bushing is reinstalled into a door stop the
tabs of the bushing will need to be aligned with
the slots in the door to reinstall the door stop.
Slots
Tab
Tab
To Next Page
