GE iBox User Manual

GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
103
Configuring the iBox PPP Driver and Internet Data Links
Procedure:
Configuring
the PPP
Driver
Step Action
1 Select the iBox device.
2 Click Communications > Options.
Result: The D2x Device Communication Options window > Interface tab
appears.
3 Select the PPP Connection Type.
Result: The tabs applicable to the connection type appear.
4 Click the Tables tab.
5 On the PPP main config tab, verify the following settings and modify
them if necessary:
Field Value
Port
COM3
Baud 19.2K
Bits per char
8
Parity Type Even
Parity Mode
None
Stop Bits 1
RTS Disable
CTS
Disable
DCD Enable
RTS on delay
0
DCD on delay 0
RTS off delay
0
Max PPP receive unit 1500
Restart timer
3
ACCM Disable
CHAP Disable
Challenge_retries
2
Challenge_period 5
Note: You should not need to change any of the above settings from
their default values. If you do, you also need to make
corresponding changes to the Digi One
®
Ethernet Module, if
equipped, or to the equipment to which the iBox Ethernet port is
connected. See “Configuring the Ethernet Module” on page 109.
6
Close the PPP Driver window.
7 Click Yes to save your changes.
Continued on next page
