GE Kelman MULTITRANS - Figure 6-2: Boot; Figure 6-3: Version; Figure 6-4: Standby Mode; Figure 6-5: Three Sources

MA-003 – MULTITRANS User Guide – Rev 3.0 18-Jan-16 Page 14 of 30
Figure 6—2: Boot
6.1.1.2 Version
If the boot sequence is successful, a Version notice reflects the product name, serial
number, firmware version and PGA version as shown in Figure 6—3. Use the black scroll
buttons at any time to page through the various notifications and data pages, including
existing measurement results.
Figure 6—3: Version
6.1.1.3 Standby
A notification indicates the operational mode as shown in Figure 6—5. Standby mode is
the initial operational mode. If scheduled measurements are configured, they will occur
automatically at the scheduled time (see Section 6.1.2.4). If there are no scheduled
measurements, the Scheduler Disabled notice displays.
or
Figure 6—4: Standby mode
Use the black scroll buttons at any time to page through any data pages for the three
sources.
Figure 6—5: Three sources
6.1.1.4 Peripheral Scheduler
A notification lists all peripheral connections as shown in Figure 6—6. If the peripheral
scheduler is enabled, all analogue inputs are listed with corresponding null values. The
product has analogue inputs AIn1 to AIn6, but corresponding values for these appear
DLM 1.2.0
CODE CHECKING
MULTITRANS
MT1-A000000
1.12.2
PGA: 4.0.0
PERIPHERAL SCHEDULER
STANDBY
>>> OK <<<
2013-07-30 10:00:00
SCHEDULER DISABLED
SOURCE 1
>>> OK <<<
SOURCE 2
>>> OK <<<
SOURCE 3
>>> OK <<<
