MA-003 – MULTITRANS User Guide – Rev 3.0 18-Jan-16 Page 15 of 30
after peripheral(s) are connected. By default, a newly shipped product has no connected
peripherals, but a configured installation may have a load sensor connected.
Figure 6—6: Peripheral scheduler
6.1.2 Manual Measurements
6.1.2.1 Start a Manual Measurement
Use the blue Start button to initiate a manual measurement on the main tank. The timer
automatically counts down from 10 seconds and then indicates the start of a manual
measurement as shown in Figure 6—7. Note: If the selected oil circuit is different from the previous
oil circuit, an oil switching notice also displays as outlined in Section 6.1.2.2.
Figure 6—7: Start a manual measurement
6.1.2.2 Oil Switching
If the current oil circuit (the one last measured) is different from the selected oil circuit to
measure, the product first needs to switch between oil circuits before a measurement
can begin. Figure 6—8 indicates switching from one circuit to another.
Figure 6—8: Oil switching
6.1.2.3 Stop a Measurement
Use the red Stop button to abort an active measurement. After any remaining oil in the
headspace drains, the product returns to Standby as shown in Figure 6—9.
PERIPHERAL SCHEDULER
DISABLED
>>> OK <<<
SOURCE 1
Analn0 0000.0uuu
Analn1 0000.0uuu
Analn2 0000.0uuu
SOURCE 1
MEASUREMENT IN
10 s
2013-07-30 11:21:00
SOURCE 1
MEASUREMENT STARTED
2013-07-30 11:21:10
SOURCE1
>>> OK <<<
2013-07-30 11:21:10
2013-07-30 11:45:00
OIL SWITCHING
2013-07-30 11:45:00
OIL DRAINING
