MA-003 – MULTITRANS User Guide – Rev 3.0 18-Jan-16 Page 17 of 30
A single press of the white Manual Sample button during Standby, selects the current oil
circuit for sampling. Subsequent presses of the button are used to toggle through and
select a different oil circuit from the three available. Once a circuit is displayed, the timer
automatically counts down from 10 seconds and if the white button is not pressed again,
the listed circuit is selected for manual oil sampling. After the count down an oil purge is
performed as shown in Figure 6—13.
Figure 6—13: Countdown & Purge
Note: The oil must be purged for a suitable period of time dependent on the installation. See the ‘Sampling
Process’ in Section 7.2.
The system prompts the user to take the manual oil sample and then returns to Standby
mode when complete as shown in Figure 6—14.
Figure 6—14: Take sample & Standby
6.1.4 Further System Specifications
6.1.4.1 Communications Channels
The product has two serial communications channels. For example, default configuration
details are shown in Figure 6—15, such as the interface, protocol, baud rate, modbus
address and parity error-checking format:
Figure 6—15: Communication channels
6.1.4.2 Networking
If Ethernet is enabled and a RJ-45 connection made, relevant network details are shown.
For security reasons, all network details are hidden by default as shown in Figure 6—16,
but these can be software enabled.
