Chapter 3: Configuration and commissioning
Kilsen KFP-CF Series Installation Manual 21
The seven-segment display
The seven-segment display is only visible when the control panel cover is removed
(see Figure 1 on page 4 and Figure 2 on page 5).
Figure 11: The seven-segment display
1. Mode LED
2. Value LED
LED Indications
Select a configuration menu using buttons 1 and 3 when this LED is steady, or Mode
Select a configuration submenu using buttons 1 and 3 when this LED is flashing.
Value Select a configuration value using buttons 2 and 4 when this LED is steady
