GE LOGIQ C Series User Manual

GE HEALTHCARE
DIRECTION 5273008-100, REVISION 9 LOGIQ C SERIES BASIC SERVICE MANUAL
6 - 2 Section 6-2 - Monitor Adjustments
Section 6-2
Monitor Adjustments
6-2-1 Adjustments Procedures
To adjust the brightness:
For LOGIQ C2/C2 PRO: Adjust the LCD monitor’s button, located the right side of the LCD Monitor.
For LOGIQ C3/C3 PRO and LOGIQ C5/C5 PRO: Adjust the LCD monitor’s button, located the bottom
of the LCD Monitor.
To adjust the light:
NOTE: If the left side button of the monitor has the light symbol, the LCD has the lights to light the keyboard.
For LOGIQ C3/C3 PRO and LOGIQ C5/C5 PRO: Adjust the left side button of the monitor to turn on/off
the light.
Figure 6-1 LCD Monitor
Figure 6-2 Light Adjustment
LOGIQ C2/C2 PRO
LOGIQ C3/C3 PRO/C5/C5 PRO
