IRECTION 5273008-100, REVISION 9 LOGIQ C SERIES BASIC SERVICE MANUAL
4 - 12 Section 4-3 - General Procedure
4-3-7 M Mode Controls
4-3-7-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-18, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already).
Figure 4-10 Controls available in M Mode
Figure 4-11 M Mode Screen Picture Example
Secondary Menu
Gain
M Cursor
Primary Menu
Power Output
Anatomical M
Dynamic Range
Colorize
Rejection
Full Timeline
Sweep Speed
Display Format
M-Mode
TGC
