IRECTION 5273008-100, REVISION 9 LOGIQ C SERIES BASIC SERVICE MANUAL
Chapter 4 Functional Checks 4 - 9
4-3-6 B Mode Checks
4-3-6-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-18, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already).
Figure 4-8 Controls available in B Mode
Figure 4-9 B Mode Screen Picture Example
Secondary Menu
Biopsy Kit
Frame Average
Line Density
Focus Width
B softener
Power Output
Suppression
Range Focus
Zoom
Depth
Scan Area
Freeze
TGC
SoftMenu Key
Frequency
Virtual Convex
Edge Enhance
Colorize
Dynamic Range
Gray Map
Rotation
Rejection
Focus Position
Focus Number
B Mode
