IRECTION 5273008-100, REVISION 9 LOGIQ C BASIC SERIES SERVICE MANUAL
3 - 10 Section 3-6 - System Configuration
Section 3-6
System Configuration
3-6-1 System Specifications
3-6-1-1 Physical Dimensions
The physical dimensions of the LOGIQ C Series unit are summarized in Table 3-4 on page 3-10 .
The Size of LOGIQ C Series.
3-6-1-2 Weight
3-6-2 Electrical Specifications
Table 3-4 Physical Dimensions of LOGIQ C Series
Height Width Depth Unit
1400 500 700 mm
55.16 19.70 27.58 inches
Table 3-5 Weight of LOGIQ C Series With Monitor and Without Other Peripherals
Model Weight [kg] Weight [lb]
LOGIQ C Series Approximately 75 Approximately 165
Table 3-6 Electrical Specifications for LOGIQ C Series
System Voltage Current Frequency
1
110 -120 V AC
500VA 50/60Hz
2
220- 240 V AC
500VA 50/60Hz
