IRECTION 5273008-100, REVISION 9 LOGIQ C SERIES BASIC SERVICE MANUAL
Chapter 4 Functional Checks 4 - 15
4-3-8 Doppler Mode Checks
NOTE: Doppler Mode is not supported by LOGIQ C2/C2 PRO.
4-3-8-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-18, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already).
Figure 4-12 Controls available in Doppler Mode
Figure 4-13 Doppler Mode Screen Picture Example
Secondary Menu
Gain
M/D Cursor
Primary Menu
Frequency
SV Length
Sweep Speed
Angle Steer
Angle Correct
Quick Angle
Baseline
Invert
PRF
Wall Filter
PW-Mode
Rejection
Dynamic Range
Display Format
Full Timeline
Trace Method
Trace Sensitivity
Trace direction
Modify, Auto Calcs
PW/CF Ratio
Duplex
Time Resolution
Colorize
Gray Map
Power Output
Auto Calcs
Spectral Average
Cycles, to Average
B Pause Cursor
TGC
