GE LOGIQ C5 Premium Service Manual

GE HEALTHCARE LOGIQ C3/C5 PREMIUM
DIRECTION 5341787-100, REVISION 8 BASIC SERVICE MANUAL
Section 7-4 - Screen Captures 7 - 7
7-4-3 Capturing a Screen (cont’d)
3.) Click FREEZE
to unfreeze the image to view the image screen and the snapshots displayed
on the bottom.
4.) Highlight the snapshot to be stored to RD (Removable Disk) or CD-R.
5.) Select Menu on the right side of the image screen, then highlight and select SAVE AS
.
Figure 7-56 Select Image to Capture
Figure 7-57 Menu > Save As
Clipboard
Thumbnai
ls
Menu
Save As

GE LOGIQ C5 Premium Specifications

General

Brand	GE
Model	LOGIQ C5 Premium
Category	Medical Equipment
Language	English
