GE HEALTHCARE LOGIQ C3/C5 PREMIUM
DIRECTION 5341787-100, REVISION 8BASIC SERVICE MANUAL
1 - 6 Section 1-2 - Important Conventions
1-2-3 Product Icons
The following table describes the purpose and location of safety labels and other important information
provided on the equipment.
Table 1-10: Product Icons
Label/Icon
Purpose/Meaning Location
Identification and Rating
Plate
• Manufacture’s name and
address
• Date of manufacture
• Model and serial numbers
• Electrical ratings (Volts,
Amps, phase, and
frequency)
Type/Class Label Used to indicate the degree of
safety or protection.
IP Code (IPX8)
IPX8: FSU-1000
Indicates the degree of
protection provided by the
enclosure per IEC60 529.
Bottom of footswitch
Type BF Applied Part (man in
the box) symbol is in
accordance with IEC 60878-
02-03.
Beside the probe
connector
General Warning. Various
“CAUTION” - Dangerous
voltage” (the lightning flash
with arrowhead) is used to
indicate electric shock
hazards.
Various
Indicates the power on and
power off position of the power
switch.
CAUTION: This Power Switch
DOES NOT ISOLATE Mains
Supply.
See the Console Overview
section for location
information.
“Protective Earth” indicates
the protective earth
(grounding) terminal.
Inside PowerBox and
Console
