GE HEALTHCARE LOGIQ C3/C5 PREMIUM
DIRECTION 5341787-100, REVISION 8 BASIC SERVICE MANUAL
Section 7-6 - Network Configuration 7 - 13
7-6-1-1 Wire-LAN Network (cont’d)
NOTE: If user want to setup static IP address, uncheck Enable DHCP
option, input static address in IP-
Address box, Subnet Mask and Default Gateway box. In Network Speed box, choose the proper
speed available.
3.) Click Save
, in popped-up dialog choose Shutdown.
4.) After the system shutdown, reboot the system.
5.) After reboot, the network icon at the left bottom of screen turns green.
Figure 7-60 Input static address
Figure 7-61 Save and reboot inquiry dialog
Figure 7-62 Network icon
To Next Page
