4–114 869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
PROTECTION CHAPTER 4: SETPOINTS
7.00 1.82 3.64 5.46 7.29 9.11 10.93 12.75 14.57 16.39 18.22 20.04 21.86 23.68 25.50 27.32
7.50 1.58 3.16 4.75 6.33 7.91 9.49 11.08 12.66 14.24 15.82 17.41 18.99 20.57 22.15 23.74
8.00 1.39 2.78 4.16 5.55 6.94 8.33 9.71 11.10 12.49 13.88 15.27 16.65 18.04 19.43 20.82
10.00 1.39 2.78 4.16 5.55 6.94 8.33 9.71 11.10 12.49 13.88 15.27 16.65 18.04 19.43 20.82
15.00 1.39 2.78 4.16 5.55 6.94 8.33 9.71 11.10 12.49 13.88 15.27 16.65 18.04 19.43 20.82
20.00 1.39 2.78 4.16 5.55 6.94 8.33 9.71 11.10 12.49 13.88 15.27 16.65 18.04 19.43 20.82
Pickup
Level
869 STANDARD “Motor” Curve TD MULTIPLIERS
x 1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x 15
PickupL
evel
869 STANDARD “Motor” Curve TD MULTIPLIERS-continued
x 16 x 17 x 18 x 19 x 20 x 21 x 22 x 23 x 24 x 25
1.01 69658 74011 78365 82719 87072 91426 95779 100133 104487 108840
1.05 13659 14513 15367 16221 17074 17928 18782 19635 20489 21343
1.10 6666.92 7083.60 7500.28 7916.96 8333.64 8750.33 9167.01 9583.69 10000 10417
1.20 3181.78 3380.64 3579.50 3778.36 3977.22 4176.08 4374.94 4573.80 4772.66 4971.52
1.30 2028.86 2155.67 2282.47 2409.28 2536.08 2662.88 2789.69 2916.49 3043.30 3170.10
1.40 1458.18 1549.32 1640.46 1731.59 1822.73 1913.87 2005.00 2096.14 2187.28 2278.41
1.50 1119.84 1189.83 1259.82 1329.81 1399.80 1469.79 1539.78 1609.77 1679.76 1749.75
1.75 678.63 721.05 763.46 805.88 848.29 890.71 933.12 975.54 1017.95 1060.37
2.00 466.53 495.69 524.84 554.00 583.16 612.32 641.48 670.63 699.79 728.95
2.25 344.49 366.02 387.55 409.08 430.62 452.15 473.68 495.21 516.74 538.27
2.50 266.56 283.22 299.88 316.54 333.20 349.86 366.52 383.18 399.84 416.50
2.75 213.24 226.56 239.89 253.22 266.55 279.87 293.20 306.53 319.86 333.18
3.00 174.91 185.85 196.78 207.71 218.64 229.57 240.51 251.44 262.37 273.30
3.25 146.33 155.47 164.62 173.76 182.91 192.06 201.20 210.35 219.49 228.64
3.50 124.38 132.15 139.92 147.70 155.47 163.24 171.02 178.79 186.56 194.34
3.75 107.11 113.81 120.50 127.20 133.89 140.59 147.28 153.98 160.67 167.37
4.00 93.28 99.11 104.94 110.77 116.60 122.43 128.26 134.08 139.91 145.74
4.25 82.00 87.12 92.25 97.37 102.50 107.62 112.75 117.87 123.00 128.12
4.50 72.68 77.22 81.76 86.31 90.85 95.39 99.93 104.48 109.02 113.56
4.75 64.88 68.94 72.99 77.05 81.11 85.16 89.22 93.27 97.33 101.38
5.00 58.29 61.94 65.58 69.22 72.87 76.51 80.15 83.80 87.44 91.08
5.50 47.83 50.82 53.81 56.80 59.79 62.78 65.76 68.75 71.74 74.73
6.00 39.97 42.47 44.97 47.46 49.96 52.46 54.96 57.46 59.96 62.45
6.50 33.91 36.03 38.15 40.27 42.39 44.51 46.63 48.75 50.87 52.99
7.00 29.14 30.97 32.79 34.61 36.43 38.25 40.07 41.89 43.72 45.54
7.50 25.32 26.90 28.48 30.07 31.65 33.23 34.81 36.40 37.98 39.56
8.00 22.20 23.59 24.98 26.37 27.76 29.14 30.53 31.92 33.31 34.69
10.00 22.20 23.59 24.98 26.37 27.76 29.14 30.53 31.92 33.31 34.69
15.00 22.20 23.59 24.98 26.37 27.76 29.14 30.53 31.92 33.31 34.69
20.00 22.20 23.59 24.98 26.37 27.76 29.14 30.53 31.92 33.31 34.69
