CHAPTER 3: INTERFACES FRONT CONTROL PANEL INTERFACE
869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 3–3
Figure 3-2: 869 Display Page Hierarchy
Working with
Graphical Display
Pages
The display contains five main menu items labeled Targets, Status, Metering, Setpoints,
and Records located at the bottom of the screen. Choosing each main menu item displays
the corresponding sub-menu.
Level 1 Level 2
Level 1 Level 2
Setpoints
Device
System
Inputs
Outputs
Protection
Monitoring
Control
FlexLogic
S
tatus
Breakers
S ches
Contact Inputs
Output Relays
Virtual Inputs
Virtual Outputs
Targets
Motor
Metering
Records
Events
Transients
Motor Start Records
Breakers
Dig Counters
Clear Records
Currents
oltages
Frequenc
Harmonics
Power
Energy
V
y
RTDs
Data Logger
Fault Reports
Motor Start Statistics
Current Demand
Power Demand
Motor Learned Data
Directional Power
Arc Flash
Arc Flash
Testing
PTP Status
Clock
Device Status
Information
Communications
Flex States
Last Trip Data
Motor
Power Factor
Analog Inputs
RTD Maximums
FlexElements
To Next Page
