For maximum settings for various capacitors (assuming 23½kΩ resistance applied in conjunction with the device),

see the table below.

C (pF) 60.00 90.00 150.00

Xc (MΩ) 53.08 35.39 21.23

VA (kV) 19.00 19.00 19.00

If (mA) 1.08 1.62 2.69

Rr (kΩ)* 22.00 22.00 22.00

Vr (V) 23.63 35.44 59.06

Vs (V) 11.81 17.72 29.53

*Relay and Resistor Combination

Voltage Setting (P144)

The device has a minimum setting on the r

esidual OV/NVD of 4V, which should provide a sensitive enough setting

for most applications. The operating voltage to be applied can be calculated for various capacitor ratings, shown

in calculations provided above.
