2.10.2 100 BASE FX TRANSMITTER CHARACTERISTICS
Parameter Sym Min. Typ. Max. Unit
Output Optical Power BOL 62.5/125 µm
NA = 0.275 Fibre EOL
PO
-19
-20
-16.8 -14 dBm avg.
Output Optical Power BOL 50/125 µm
NA = 0.20 Fibre EOL
P
O
-22.5
-23.5
-20.3 -14 dBm avg.
Optical Extinction Ratio
10
-10
%
dB
Output Optical Power at Logic "0" State PO -45 dBm avg.
Conditions: TA = 0°C to 70°C
