7. Remove the redundant Ethernet board. Set the last octet of IP address using the DIP switches. The available

range is 1 to 127.

V01022

Unused

SW2 Top view

Example address

decimal 85

1 + 4 + 16 + 64 = 85

8. Once you have set the IP address, reassemble the IED, following theses instructions in the reverse order.

Warning:

ake care not to damage the pins of the ribbon cable connector on the front panel when reinserting

the ribbon cable.
