GE MiCOM P145 Agile User Manual

Object
Request
(Library will par
se)
Response
(Library will respond with)
Object
Number
Variation
Number
Description
Function Codes (dec) Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes (hex)
21 10 16-Bit Frozen Counter without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
`22 0 Counter Change Event - Any
Variation
1
(read) 06
07, 08
(no range, or all)
(limited qty)
22 1
(default - see
note 1)
32-Bit Counter Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
22 2 16-Bit Counter Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
22 5 32-Bit Counter Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
22 6 16-Bit Counter Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 0 Frozen Counter Event (Variation 0
is used to request default
variation)
1 (read) 06
07, 08
(no range, or all)
(limited qty)
23 1
(default - see
note 1)
32-Bit Frozen Counter Event 1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 2 16-Bit Frozen Counter Event 1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 5 32-Bit Frozen Counter Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 6 16-Bit Frozen Counter Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
30 0 Analog Input - Any Variation 1
22
(read)
(assign class)
00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
30 1 32-Bit Analog Input 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 2 16-Bit Analog Input 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 3
(default - see
note 1)
32-Bit Analog Input without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 4 16-Bit Analog Input without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 5 Short floating point 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
32 0 Analog Change Event - Any
Variation
1
(read) 06
07, 08
(no range, or all)
(limited qty)
32 1
(default - see
note 1)
32-Bit Analog Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 2 16-Bit Analog Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 3 32-Bit Analog Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 4 16-Bit Analog Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 5 Short floating point Analog
Change Event without Time
1
(read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 7 Short floating point Analog
Change Event with Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
P14x Chapter 18 - Communications
P14xEd1-TM-EN-1 425
