Disturbance record states
State Description
Idle
This will be the state reported when no record is selected; such as after power on or after a record has been
marked as extracted.
Busy The r
elay is currently processing data.
Page ready The data page has been populated and the master station can now safely read the data.
Configuration complete All of the configuration data has been read without error.
Record complete All of the disturbance data has been extracted.
Disturbance overwritten
An error occurred during the extraction process where the disturbance being extracted was overwritten by a
new record.
No non-extracted disturbances
An attempt was made by the master station to automatically select the next oldest non-extracted
disturbance when all records have been extracted.
Not a valid disturbance An attempt was made by the master station to manually select a record that did not exist in the relay.
Command out of sequence The master station issued a command to the relay that was not expected during the extraction process.
7.4.6.1 MANUAL EXTRACTION PROCEDURE
The procedure used to extract a disturbance manually is shown below. The manual method of extraction does not
allow for the acceptance of disturbance r
ecor
ds.
P14x Chapter 18 - Communications
P14xEd1-TM-EN-1 435
