MM200 MOTOR MANAGEMENT SYSTEM – QUICK START GUIDE 5
MM200 Motor Management System
Chapter 2: Installation
GE
Grid Solutions
Instal lation
Mechanical installation
This section describes the mechanical installation of the MM200 system, including
dimensions for mounting.
Dimensions
The MM200 is packaged in a fixed format divided into three specific sections.
The dimensions of the MM200 are shown below. Additional dimensions for mounting are
shown in the following sections.
