Page #35 background imageLoading...
Page #35 background image
30 MM200 MOTOR MANAGEMENT SYSTEM – QUICK START GUIDE
OUTPUTS SPECIFICATIONS CHAPTER 6: SPECIFICATIONS
Outputs specifications
OUTPUT RELAYS
Configuration: ...................................................... electromechanical 2 x Form-A and 1 x Form-C
Contact material:................................................ silver-alloy
Operate time:........................................................ 10 ms
Minimum contact load:.................................... 10 mA at 5 V DC
Maximum switching rate:............................... 300 operations per minute (no load), 30 operations per
minute (load)
Mechanical life:.................................................... 10 000 000 operations
Continuous current:........................................... 5 A at 60°C
Make and carry for 0.2s:.................................. 30 A per ANSI C37.90 (not UL rated)
OUTPUT RELAY BREAK CAPACITY (FORM-A RELAY)
AC resistive, 120 V AC: ...................................... 5 A
AC resistive, 250 V AC: ...................................... 5 A
AC inductive, PF = 0.4:....................................... 240 VA pilot duty
DC resistive, 30 V DC:........................................ 5 A
OUTPUT RELAY BREAK CAPACITY (FORM-C RELAY)
AC resistive, 120 V AC: ...................................... 5 A normally-open, 5 A normally-closed
AC resistive, 240 V AC: ...................................... 5 A normally-open, 5 A normally-closed
AC inductive, PF = 0.4:....................................... 240 VA pilot duty
DC resistive, 30 V DC:........................................ 5 A
Power supply specifications
POWER SUPPLY (LO RANGE)
Nominal:.................................................................. 24 V DC
Range:...................................................................... 18 to 36 V DC
Power Consumption:......................................... 10 W typical
POWER SUPPLY (HI RANGE)
Nominal:.................................................................. 120 to 240 V AC; 125 to 250 V DC
Range:...................................................................... 60 to 300 V AC (50 and 60 Hz); 84 to 250 V DC
Power consumption: ......................................... 10 W typical
Voltage withstand:............................................. 2 × highest nominal voltage for 10 ms
Communications specifications
DEVICENET (COPPER)
Modes: ..................................................................... slave (125, 250, and 500 kbps)
Connector: ............................................................. 5-pin terminal
Current Draw:....................................................... 80 mA at 24 VDC
PROFIBUS (COPPER)
Modes: ..................................................................... DP V0 slave, up to 1.5 Mbps
Connector: ............................................................. 5-pin terminal
