1–10 MM200 MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
SPECIFICATIONS CHAPTER 1: INTRODUCTION
OUTPUT RELAY BREAK CAPACITY (FORM-A RELAY)
AC resistive, 120 V AC: ...................................... 5 A
AC resistive, 250 V AC: ...................................... 5 A
AC inductive, PF = 0.4:....................................... 240 VA pilot duty
DC resistive, 30 V DC:........................................ 5 A
OUTPUT RELAY BREAK CAPACITY (FORM-C RELAY)
AC resistive, 120 V AC: ...................................... 5 A normally-open, 5 A normally-closed
AC resistive, 240 V AC: ...................................... 5 A normally-open, 5 A normally-closed
AC inductive, PF = 0.4:....................................... 240 VA pilot duty
DC resistive, 30 V DC:........................................ 5 A
Power supply specifications
POWER SUPPLY (LO RANGE)
Nominal:.................................................................. 24 V DC
Range:...................................................................... 18 to 36 V DC
Power Consumption:......................................... 10 W typical
POWER SUPPLY (HI RANGE)
Nominal:.................................................................. 120 to 240 V AC
Range:...................................................................... 60 to 300 V AC (50 and 60 Hz)
Power consumption: ......................................... 10 W typical
Voltage withstand: ............................................. 2 × highest nominal voltage for 10 ms
Communications specifications
DEVICENET (COPPER)
Modes: ..................................................................... slave (125, 250, and 500 kbps)
Connector: ............................................................. 5-pin terminal
Current Draw:....................................................... 80 mA at 24 VDC
PROFIBUS (COPPER)
Modes: ..................................................................... DP V0 slave, up to 1.5 Mbps
Connector: ............................................................. 5-pin terminal
RS485 PORT
Port:........................................................................... opto-isolated
Baud rates: ............................................................ up to 115 kbps
Protocol:.................................................................. Modbus RTU, half-duplex
Maximum distance:........................................... 1200 m
Isolation: ................................................................. 2 kV
Testing and certification
TYPE TESTS
Test Reference Standard Test Level
Dielectric voltage withstand 2.3KV
Impulse voltage withstand EN60255-5 5KV
Damped Oscillatory IEC61000-4-18IEC60255-22-1 2.5KV CM, 1KV DM
Electrostatic Discharge EN61000-4-2/IEC60255-22-2 Level 4
RF immunity EN61000-4-3/IEC60255-22-3 Level 3
Fast Transient Disturbance EN61000-4-4/IEC60255-22-4 Class A
Surge Immunity EN61000-4-5/IEC60255-22-5 Level 3
Conducted RF Immunity EN61000-4-6/IEC60255-22-6 Level 3
