1–6 MM200 MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
OVERVIEW CHAPTER 1: INTRODUCTION
MM200 order codes
The information to specify an MM200 relay is provided in the following order code figure.
Figure 1-3: MM200 order codes
NOTE:
Harsh Environment Coating is a standard feature on all MM200 units.
Example of an MM200 order code
MM200-BXL1S: MM200 with basic control panel, 24 V DC power supply, RS485 Modbus
RTU communications, three-phase current, thermal overload, undercurrent, Devicenet
communications, protection option.
888702A3.PDF
Base
MM200 * X * * * Description (7 inputs, 2 Form A, 1 Form C, 3 CT, CBCT,
Thermistor)
MM200 | | | | MM200 Motor Management System
Control panel X | | | No Control Panel
B | | | Basic Control Panel, no USB
G | | | Graphical control panel with USB
Power supply H |
|
|
|
6 AC Digital inputs 65 to 300 V AC, 3 Outputs (2 form A, 1
form C), 3CT, CBCT, thermistor
L|
|
|
|
7 DC digital inputs 24 V DC, 3 Outputs (2 form A, 1 form C),
3CT, CBCT, thermistor
Communications 1 | RS485 Modbus RTU plus DeviceNet Slave
2 | RS485 plus Profibus DP slave
S | Standard Communications: RS485 Modbus RTU
Protection S Standard Protection and Control
