1–12 MM200 MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
SPECIFICATIONS CHAPTER 1: INTRODUCTION
Physical specifications
DIMENSIONS
Size: ........................................................................... Base: 78 mm (W) × 90 mm (H) × 113 mm (D) [+ terminals
10mm]
BCP: 75 mm (W) × 75 mm (H) × 31 mm (D)
GCP: 153 mm (W) × 102 mm (H) × 35 mm (D)
Weight (Base):....................................................... 0.5 kg
Environmental specifications
OPERATING ENVIRONMENT
Ambient temperatures:
Storage/shiipping: - 40C to 90C *
Operating: -20C to 60C *
Humidity Operating up to 95% (non condensing) @ 55C (As per
IEC60068-2-30 Variant 2, 6days)
Altitude: 2000m (max)
Pollution Degree: II
Overvoltage Category: II
Ingress protection: IP20 (base unit) , IP54 (Control Panel)
Environmental rating; 60C surrounding Air ,pollution degree II,Type 1 (panel
mount versions only)
Noise: 0 dB
* 1" around base unit
