QUICK REFERENCE GUIDE
469 MOTOR MANAGEMENT RELAY – QUICK REFERENCE GUIDE 3
Programming can be accomplished via the front panel. To simplify programming and
provide a more intuitive interface, setpoints can also be entered with a PC running the no-
charge EnerVista 469 setup software provided with the relay. Actual values and setpoints
can be displayed, altered, stored, and printed. If settings are stored in a setpoint file, they
can be downloaded at any time to the front panel program port of the relay via a
computer cable connected to the serial port of any personal computer.
Table 1: Summary of Protection, Control & Monitoring Functions
ANSI DESCRIPTION
51 Overload
86 Overload lockout
66 Starts/hour and Time between starts
--- Restart block (Anti-backspin timer)
50 Short circuit and Short circuit backup
--- Mechanical jam
37 Undercurrent/Underpower
32 Reverse power
46 Current unbalance
50G/51G Ground fault and Ground fault backup
87 Differential
--- Acceleration
49 Stator RTD
38 Bearing RTD
--- Other RTD and Ambient RTD
--- Open RTD alarm
--- Short/Low RTD
27/59 Undervoltage/Overvoltage
47 Phase reversal
81 Frequency
--- Reactive power
55/78 Power factor
--- Analog input
--- Demand alarm: A, kW, kvar, and kVA
--- 469 self-test, Service
--- Trip coil supervision
--- Welded contactor
--- Breaker failure
--- Remote switch
14 Speed switch and Tachometer trip
--- Load shed switch
--- Pressure switch
--- Vibration switch
19 Reduced voltage start
48 Incomplete sequence (Reduced voltage
start)
--- Remote start/stop
--- Overtorque
--- Forced relay operation
