GE Multilin EPM 2000 Series

GE Multilin Sub Meters 24
Table 2-4: Editing the Setup Values
First, you must enter the Main Menu and reach “SET” using the previous Table. This example
illustrates changing System Mode (SYS) from “Star” to “Delta”.
Action Display Remarks
"Set" You’re in the Main Menu.
Press  to enter SET SYS
V.PRI
V.SEC
Wiring System.
Voltage primary.
Voltage secondary.
Press  to edit "StAR"
415.0
415.0
Wiring System = Star 3E
Voltage primary = 415v.
Voltage secondary = 415v.
We have now reached SYS (top
row) for editing.
Press  to view Value.
"StAR"
415.0
415.0
Wiring System = Star 3E
Voltage primary = 415v.
Voltage secondary = 415v.
Press  to edit SYS value.
The value blinks.
" Star "
415.0
415.0
Blinks. Only Top Row is edited
Ignore
Ignore
Press  to change to Delta 2E. " Delta "
415.0
415.0
Blinks. Note: To discard the change:
• Press .
•
Restores the previous value.
Press  to accept the value. "Delta"
415.0
415.0
Steady. SYS is now set to Delta.
Press  to scroll down, and  to change
other values.
We’re done. Press  to head
back.
" SYS "
Blinks
Press  again. "Save"
" y "
NOTE: To discard present changes, press
to
show “Save n”.
Press  to accept "y" (yes, save) "PASS"
“Set”
Stores the Setup changes.
Now, you’re back in the Main Menu and can
go  to “RUN” and  to “RMS”.
