GE NetworX NX-6V2 User Manual

28
NX-6V2 Control
146 ZONE TYPE 19 ALARM EVENT CODE 1 ............ numerical
Location 146 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
147 ZONE TYPE 19 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
148 ZONE TYPE 20 ALARM EVENT CODE 1 ............ numerical
Location 148 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
149 ZONE TYPE 20 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
150 ZONE TYPE 21 ALARM EVENT CODE 1 ............ numerical
Location 150 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
151 ZONE TYPE 21 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
152 ZONE TYPE 22 ALARM EVENT CODE 1 ............ numerical
Location 152 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
153 ZONE TYPE 22 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
154 ZONE TYPE 23 ALARM EVENT CODE 1 ............ numerical
Location 154 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
155 ZONE TYPE 23 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
156 ZONE TYPE 24 ALARM EVENT CODE 1 ............ numerical
Location 156 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
157 ZONE TYPE 24 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
158 ZONE TYPE 25 ALARM EVENT CODE 1 ............ numerical
Location 158 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
159 ZONE TYPE 25 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
160 ZONE TYPE 26 ALARM EVENT CODE 1 ............ numerical
Location 160 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
161 ZONE TYPE 26 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
162 ZONE TYPE 27 ALARM EVENT CODE 1 ............ numerical
Location 162 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
163 ZONE TYPE 27 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
164 ZONE TYPE 28 ALARM EVENT CODE 1 ............ numerical
Location 164 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
165 ZONE TYPE 28 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25

GE NetworX NX-6V2 Specifications

Power

operating power	16.5 VAC 40, or 50 VA Transformer
auxiliary power with 25 VA Transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA Transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E Power Supply	12 VDC Regulated 2 AMPS + Control Panel Power

Loop Specifications

loop resistance standard loop	300 Ohms Maximum
loop resistance 2-wire smokes	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F

Keypad Specifications

LED keypad current draw	130 mA max.
LED keypad zones normal without sounder	55 mA
LED keypad dimensions	6.4" Wide, 4.0" High, 1.1" Deep
NX148E LCD keypad current draw	110 mA max.
NX148E LCD keypad without sounder	75 mA
NX148E LCD keypad dimensions	6.4" Wide, 5.3" High, 1.0" Deep

Dimensions and Weight

metal enclosure dimension	11.25" Wide, 11.25" High, 3.50" Deep
shipping weight	9 lbs.
