NX-8E CONTROL
54
LOC PG
DESCRIPTION DEFAULT DATA
69 28 LOW BATTERY / LOW BATTERY RESTORE 0-0-0-0 _ _ _ _
70 28 POWER SHORT / POWER SHORT RESTORE 0-0-0-0 _ _ _ _
71 28 BELL TAMPER / BELL TAMPER RESTORE 0-0-0-0 _ _ _ _
72 28 TELEPHONE LINE CUT / LINE CUT RESTORE 0-0-0-0 _ _ _ _
73 28 GROUND FAULT / GROUND FAULT RESTORE 0-0-0-0 _ _ _ _
74 29 EXPANDER TROUBLE / EXP TROUBLE RESTORE 0-0-0-0 _ _ _ _
75 29 FAILURE TO COMMUNICATE 0-0 _ _
76 29 LOG FULL COMMUNICATOR CODE 0-0 _ _
OPENING CODE COMMUNICATOR CODE
Segment #1: Opening Code for Partition #1 0 _
Segment #2: Opening Code for Partition #2 0 _
Segment #3: Opening Code for Partition #3 0 _
Segment #4: Opening Code for Partition #4 0 _
Segment #5: Opening Code for Partition #5 0 _
Segment #6: Opening Code for Partition #6 0 _
Segment #7: Opening Code for Partition #7 0 _
77
29
Segment #8: Opening Code for Partition #8 0 _
78 29 CLOSING COMMUNICATOR CODE
Segment #1: Closing Code for Partition #1 0 _
Segment #2: Closing Code for Partition #2 0 _
Segment #3: Closing Code for Partition #3 0 _
Segment #4: Closing Code for Partition #4 0 _
Segment #5: Closing Code for Partition #5 0 _
Segment #6: Closing Code for Partition #6 0 _
Segment #7: Closing Code for Partition #7 0 _
Segment #8: Closing Code for Partition #8 0 _
79 29 AUTOTEST COMMUNICATOR CODE 0-0 _ _
80 29 RECENT CLOSING AND EXIT ERROR 0-0 _ _
81 29 START PROGRAMMING / END PROGRAMMING 0-0-0-0 _ _ _ _
82 29 END DOWNLOAD 0-0-0-0 X X _ _
83 29 CANCEL COMMUNICATOR CODE 0 _
84-87 29 RESERVED 0-0-0-0 Reserved
88 30 PARTITION 1, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _
89 30 PARTITION 2, ACCOUNT CODE 10-10-10-10-10-10 _ _ __ _ _
PARTITION 2, FEATURE AND REPORTING SELECTION
Segment #1
1
2
3
4
Quick Arm
Re-Exit
Auto Bypass
Silent Panic
5
6
7
8
Audible Panic
Auxiliary 1
Auxiliary 2
Multi Keypress Tamper
Segment #2
1
2
3
4
LED extinguish enable
Require user code for bypassing zones
Bypass sounder alert
AC power/low battery sounder alert
5
6
7
8
Enables bypass toggle
Enables silent auto arm
Enables automatic instant
Reserved
Segment #3
1
2
3
4
Open/Close
Bypass
Restore
Trouble
5
6
7
8
Tamper
Cancel
Recent Closing
Exit Error
Segment #4
1
2-8
Late to Close / Early to Open
Reserved
90 30
Segment #5 RESERVED
