GE NetworX Series Installation And Start-Up Manual

NX-8E CONTROL
65
NX-584 COMMAND/REQUEST ENABLE
Segment #1 Segment #2
1 = Reserved
2 = Interface Configuration Request
3 = Reserved
4 = Zone Name Request
5 = Zone Status Request
6 = Zones Snapshot Request
7 = Partition Status Request
8 = Partitions Snapshot Request
1 = System Status Request
2 = Send X-10 Message
3 = Log Event Request
4 = Send Keypad Text Message
5 = Keypad Terminal Mode Request
6-8 = Reserved
Segment #3 Segment #4
211 43
1 = Program Data Request
2 = Program Data Command
3 = User Information Request with PIN
4 = User Information Request without PIN
5 = Set User Code Command with PIN
6 = Set User Code Command without PIN
7 = Set User Authorization Comm with PIN
8 = Set User Authorization Comm without PIN
1-2 = Reserved
3 = Store Communication Event Command
4 = Set Clock / Calendar Command
5 = Primary Keypad Function with PIN
6 = Primary Keypad Function without PIN
7 = Secondary Keypad Function
8 = Zone Bypass Toggle
212 44 LCD KEYPAD ADDRESS FOR NX-584
192
213 RESERVED
KP PART 1 PART 2 PART 3 PART 4 PART 5 PART 6 PART 7 PART 8
1 192 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255

GE NetworX Series Specifications

General

Model	NetworX Series
Zones	Varies by model (e.g., 8, 16, 32, 64)
Partitions	Varies by model (typically 1-8)
Keypads	Supports multiple keypads
Communication	Phone line, cellular, IP
Power Supply	16.5 VAC
Backup Battery	12VDC, 7AH
User Codes	Varies by model (e.g., 48, 150, 300)
Event Buffer	Varies by model (e.g., 200, 500, 1000 events)
Operating Temperature	0°C to 49°C (32°F to 120°F)
Communication Protocol	Contact ID, SIA
Weight	Varies by model
Dimensions	Varies by model (e.g., 14.5" x 12.5" x 3.5")
