GE NetworX Series Installation And Start-Up Manual

NX-8E CONTROL
64
LOC PG DESCRIPTION DEFAULT DATA
L
204 41 ZONES 185-192, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _
ZONES 185-192, PARTITION SELECTION (Segment 1=Zone 185 thru Segment 8=Zone 192)
Segments 1 2 3 4 5 6 7 8
205 41
Partition #1
Partition #2
Partition #3
Partition #4
Partition #5
Partition #6
Partition #7
Partition #8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
DAYS OF THE WEEK "AUTO DISARMING" WILL OCCUR IN PARTITIONS 1-8
Segments 1 2 3 4 5 6 7 8
206 42
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Reserved
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
SERIAL PORT ENABLE 0 _ 207 42
0 = Disabled
1 = Home Automation Protocol Enabled
2 = Serial Printer Mode
SERIAL PORT BAUD RATE 2 208 42
0 = 2400 (2.4K)
1 = 4800 (4.8K)
2 = 9600 (9.6K)
3 = 19200 (19.2K)
4 = 38400 (38.4K)
5-7 = Reserved
HOME AUTOMATION PROTOCOL Off 209 42
LED Off = Binary LED On = ASCII
NX8E TRANSITION-BASED BROADCASTS
Segment #1 Segment #2
210 42
1 = Reserved
2 = Interface Configuration
3-4 = Reserved
5 = Zone Status Message
6 = Zones Snapshot Message
7 = Partition Status Message
8 = Partitions Snapshot Message
1 = System Status Message
2 = X-10 Message Received
3 = Log Event Message
4 = Keypad Message Received
5 –8 = Reserved
