GE NetworX Series Installation And Start-Up Manual

NX-8E CONTROL
72
XVIII. APPENDIX 4
USER ID OR ZONE ID HEX DIGIT FOR 4+2 FORMATS
The following appendix applies only to slow formats (locations 56- 83 lower digit). The digit programmed in the
locations will be sent as the upper HEX digit in place of the alarm event code. The zone ID or user ID will always be
reported as the lower HEX digit (1-F) as shown in the chart below. For example, if the zone ID or user ID is 15, the 4+2
lower digit will be “F” and if the zone ID or user ID is 166, the 4+2 digit will be “1”. Use the chart shown below for
convenience. NOTE
: If Segments 2-8 are left as “0” (unprogrammed), they will follow the Segment 1 selection. If
Segment 1 is left as “0” and the feature is enabled in Location 23, the NX8E will report “A”.
ZONE ZONE ZONE ZONE ZONE ZONE
USER
HEX
USER
HEX
USER
HEX
USER
HEX
USER
HEX
USER
HEX
1 1 41 B 81 6 121 1 161 B 201 6
2 2 42 C 82 7 122 2 162 C 202 7
3 3 43 D 83 8 123 3 163 D 203 8
4 4 44 E 84 9 124 4 164 E 204 9
5 5 45 F 85 A 125 5 165 F 205 A
6 6 46 1 86 B 126 6 166 1 206 B
7 7 47 2 87 C 127 7 167 2 207 C
8 8 48 3 88 D 128 8 168 3 208 D
9 9 49 4 89 E 129 9 169 4 209 E
10 A 50 5 90 F 130 A 170 5 210 F
11 B 51 6 91 1 131 B 171 6 211 1
12 C 52 7 92 2 132 C 172 7 212 2
13 D 53 8 93 3 133 D 173 8 213 3
14 E 54 9 94 4 134 E 174 9 214 4
15 F 55 A 95 5 135 F 175 A 215 5
16 1 56 B 96 6 136 1 176 B 216 6
17 2 57 C 97 7 137 2 177 C 217 7
18 3 58 D 98 8 138 3 178 D 218 8
19 4 59 E 99 9 139 4 179 E 219 9
20 5 60 F 100 A 140 5 180 F 220 A
21 6 61 1 101 B 141 6 181 1 221 B
22 7 62 2 102 C 142 7 182 2 222 C
23 8 63 3 103 D 143 8 183 3 223 D
24 9 64 4 104 E 144 9 184 4 224 E
25 A 65 5 105 F 145 A 185 5 225 F
26 B 66 6 106 1 146 B 186 6 226 1
27 C 67 7 107 2 147 C 187 7 227 2
28 D 68 8 108 3 148 D 188 8 228 3
29 E 69 9 109 4 149 E 189 9 229 4
30 F 70 A 110 5 150 F 190 A 230 5
31 1 71 B 111 6 151 1 191 B 231 6
32 2 72 C 112 7 152 2 192 C 232 7
33 3 73 D 113 8 153 3 193 D 233 8
34 4 74 E 114 9 154 4 194 E 234 9
35 5 75 F 115 A 155 5 195 F 235 A
36 6 76 1 116 B 156 6 196 1 236 B
37 7 77 2 117 C 157 7 197 2 237 C
38 8 78 3 118 D 158 8 198 3 238 D
39 9 79 4 119 E 159 9 199 4 239 E
40 A 80 5 120 F 160 A 200 5 240 F
