case any neighbouring premises also has an X-10 home automation system.
More information on the X-10 home automation system can be found at www.x-
10europe.com.
Invert Aux Output
A menu option that enables a mode that inverts the state of an output (normally activated
and then deactivated when an event occurs).
Keyfob Funct 1
A menu option that sends a keyfob function 1 event for the selected NX-1750 ProxPad
action. The actions are Single Badge, Double Badge and Badge Hold.
Keyfob Funct 2
A menu option that sends a keyfob function 2 event for the selected NX-1750 ProxPad
action. The actions are Single Badge, Double Badge and Badge Hold.
LED Extinguish A menu option that turns off all the status LEDs.
Log Forced Entry A menu option that records a forced entry event in the event log.
Log RTE (Card)
A menu option that records an RTE (Card) event in the event log. An RTE (Card) event is a
request to exit by scanning a card.
Log RTE (Zone)
A menu option that records an RTE (Zone) event in the event log. An RTE (Zone) event is a
request to exit by activating a zone.
Logging Partition
A menu option that specifies the partition number that the NX-1750 ProxPad adds to any
event that it records in the event log. This allows users to know which reader was scanned
for access.
Maglock or Drop Bolt lock A menu option that specifies the door lock type.
Miscellaneous A menu entry that groups some miscellaneous options.
Model A menu option that displays the current model of the NX-1750 ProxPad.
No armed egress A menu entry that disables the Egress input when the ProxPad is armed.
Only if Closed
A menu option that activates the selected NX-1750 ProxPad after closing time and before
opening time. During these times, a card can be used to arm/disarm the system. A timer is
used to set these times.
Only if Open
A menu option that activates the selected NX-1750 ProxPad between opening time and
closing time. During these times, a card can be used to arm/disarm the system. A timer is
used to set these times.
Opening A menu option that sets the time at which the selected schedule enters the open state.
Relay Active Time
A menu option that sets the length of time the relay is activated when a proximity card is
held against the NX-1750 ProxPad.
Reset Settings A menu option that defaults the selected NX-1750 ProxPad to factory defaults.
Scan Time
A menu option that specifies the length of time during which the proximity card must be
held near the NX-1750 ProxPad to activate its functions. A NX-1750 ProxPad can be
programmed to activate different functions depending on whether the card is held near it
once, twice within this time or continuously for this time.
Schedules
A menu option that, combined with Output Schedule Selection, selects the schedules that
affect the NX-1750 ProxPad.
Send Code Entry Function
A menu option that enables the send code entry function for the selected NX-1750 ProxPad
action. The actions are Single Badge, Double Badge and Badge Hold. This function sends the
same command to the control panel, using the proximity card, as a keypad would send if a
valid code were entered. For example, if the system is armed, the selected action disarms it.
Single Badge (1 Beep)
A menu entry that groups the functions activated by holding a proximity card once against
the NX-1750 ProxPad.
A menu option that sets the X-10 function sent when a proximity card is held against the
NX-1750 ProxPad once.
Start Zone An menu option that specifies the first zone number of zones on the RF receiver.
Tamper
A menu option that sends a report to the central station when there is interference with the
NX-1750 ProxPad.
Unit Code A menu option that sets the X-10 unit number used to identify a particular X-10 device.
User Card 1 A menu option that selects the user card to program.
User Card Programming A menu option that enables user cards to be programmed.
User Cards A menu entry that groups the options for programming the user cards.
