NX-10 Expander Installation Guide
71
Option Function
ON Code will activate Output A 1
OFF
Code will NOT activate output A
ON Code will activate Output B 2
OFF
Code will NOT activate output B
ON Code will activate Output C 3
OFF
Code will NOT activate output C
4-8 Reserved
LOCATION 9 - AUTHORIZING USERS 11 - 20 TO TRIGGER OUTPUTS A-C (10 segments, feature
selection data)
When activating outputs with a user code (event 30), location 9 can be used to restrict certain codes
from activating certain outputs. Location 9 contains 10 segments. Segment 1 corresponds to user 11,
segment 10 corresponds to user 20.
Refer to location 8 chart.
LOCATION 10 - AUTHORIZING USERS 21 - 30 TO TRIGGER OUTPUTS A-C (10 segments, feature
selection data)
When activating outputs with a user code (event 30), location 10 can be used to restrict certain codes
from activating certain outputs. Location 10 contains 10 segments. Segment 1 corresponds to user 21,
segment 10 corresponds to user 30.
Refer to location 8 chart.
LOCATION 11 - AUTHORIZING USERS 31 - 40 TO TRIGGER OUTPUTS A-C (10 segments, feature
selection data)
When activating outputs with a user code (event 30), location 11 can be used to restrict certain codes
from activating certain outputs. Location 11 contains 10 segments. Segment 1 corresponds to user 31,
segment 10 corresponds to user 40.
Refer to location 8 chart.
LOCATION 12 - AUTHORIZING USERS 41-50 TO TRIGGER OUTPUTS A-C (10 segments, feature
selection data)
When activating outputs with a user code (event 30), location 12 can be used to restrict certain codes
from activating certain outputs. Location 12 contains 10 segments. Segment 1 corresponds to user 41,
segment 10 corresponds to user 50.
Refer to location 8 chart.
