GE Optima IGS 320 - Page 181

MIS num‐
ber
Cable As‐
sembly
UL Style Voltage rating
(V)
Max Voltage
carried (V)
Cable di‐
ameter
(mm)
Connector type Bigger Plug
size (mm)
27665A 5506726-x 2463 300 9.2 Metrimate 6 pin 29
27666A 5506563-x WATER HOSE
27667A 5506563-x WATER HOSE
27468A 5507762-x 1019 600 9.1 Pre-stripping, ring terminal 12
27473A 5507762-x 1019 600 9.1 Pre-stripping, ring terminal 12
27670A 5404120-x 2789 300 HES 15 pin
27510A 5506562-x WATER HOSE
27511A 5506562-x WATER HOSE
27512A 5506560-x FIBER OPTIC
27514A 5191772-x 2789 30 7.3 DB 26 pin 41.2
27675A 5506579-x Type CL2 150 8.2 Pre-stripping 8.2
27662A 5641187-x 30 7 AMP 8 pin RJ45
27669A 5506561-x 2464 300 16.2 Circular connector 47.8
27671A 5506577-x 2789 30 10.9 Amplimite 100 pin 84.6
27673A 5506577-x 2789 30 10.9 Amplimite 100 pin 84.6
27672A 5506577-x 2789 30 10.9 Amplimite 100 pin 84.6
27674A 5506574-x 2464 300 10.6 DB 25 pin 56.6
27722A 5404123 300 15 AMP 25 pin 55
29172A 5506917-x 2464 300 12.7
Group no.2 (From System Control Cabinet to Control Booth)
27676A 5506786-x 300 8.3 SCSI.50 60
27472A 5506802-x 4299 300 250
8 plug power strip CEI320 -
(HBL4570C plug - ring termi‐
nal) 39
27492A 5506799-x 1354
27493A 5506785-x Category 5 150 5.5 RJ45 14.1
27494A 5506805-x 2464 300 6 DB 9 pin 30.9
27505A 5506785-x Category 5 150 5.5 RJ45 14.1
29010A 5506782 2464 300 IEC Power Connectors
29011A 5506782 2464 300 IEC Power Connectors
29012A 5506782 2464 300 IEC Power Connectors
29013A 5506783-x 2464 300 IEC Power Connectors
29024A 5506782 2464 300 IEC Power Connectors
29041A 5506804
Group no.3 (Between parts in Technical room)
27677A 5506739-2 2463 600 8.3 Metrimate 6 pin 29.8
27678A/
28260A 5506777-x Type CL2
Low Volt-age
SCSI 10 SCSI 50C 77
