GE Optima IGS 320 - Page 182

MIS num‐
ber
Cable As‐
sembly
UL Style Voltage rating
(V)
Max Voltage
carried (V)
Cable di‐
ameter
(mm)
Connector type Bigger Plug
size (mm)
27679A 5405108 Fiber Optic
27522A 5506729-2 2464 300 7 CEI 320 - HBL4570C plug 38.6
27523A 5506733-2
27680A 5305580 600
27681A 5398308
27682A 5506769-4
27683A 5405109
27684A 5305576
27686A 5305570 2464 300 8.1 DB 9 pin 34.4
28254A 5506737-2
27561A 5506773-4
53030 5488619
Group no. 4-4 (LCD Suspension)
28045 2385191-x 30V VGA
28046 2385192-x 30V VGA
28047 2385191-9 30V VGA
28048 2385192-9 30V VGA
28049 2385191-x 30V VGA
28050 2385192-x 30V VGA
28051 2385191-x
28052 2385192-x
28053 2385191-x
28054 2385192-x
28066 5314764-7 1354 30V BNC 14.4
28067 5314765-7 1354 30V BNC 14.4
28068 5314764-8 1354 30V BNC 14.4
28069 5314765-8 1354 30V BNC 14.4
28070 5314764-7 1354 30V BNC 14.4
28071 5314765-7 1354 30V BNC 14.4
28072 5314764-8 1354 30V BNC 14.4
28073 5314765-8 1354 30V BNC 14.4
28074 5314764-9 1354 30V BNC 14.4
28075 5314765-9 1354 30V BNC 14.4
28076
5314764-1
0 1354 30V BNC 14.4
28077
5314765-1
0 1354 30V BNC 14.4
Optima IGS 320, Optima IGS 330 Pre-Installation Manual
Direction 5537562-1-1EN, Revision 3
182 2 System Cable Information
