GE P54E - GROUP 1: OVERCURRENT

P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B7
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
I1 High
V2 Low
V2 High
Z2 Low
Z2 High
Z3 Low
Z3 High
Z4 Low
Z4 High
Zp Low
Zp High
[Binary Flag (32) Indexed String]
Displays the status of the second 32 start signals.
Trip Elements(1) 01 0A
Any Trip
Trip I Diff
InterTrip I Diff
PIT
Trip Z1
Trip Z2
Trip Z3
Trip ZP
Trip Z4
Aid 1 Dist Trip
Aid 1 Delta Trip
Aid 1 DEF Trip
Aided 1 WI
Aid 2 Dist Trip
Aid 2 Delta Trip
Aid 2 DEF Trip
Aided 2 WI
TOR
SOTF
LOL
Stub Bus Trip
Trip F<1
Trip F<2
Trip F<3
Trip F<4
Trip F>1
Trip F>2
Trip df/dt>1
Trip df/dt>2
Trip df/dt>3
Trip df/dt>4
Phase Comparison
[Binary Flag (32) Indexed String]
Displays the status of the first 32 trip signals.
Trip Elements(2) 01 0B
Trip I>1
Trip I>2
Trip I>3
Trip I>4
Trip Broken Line
Trip IN1>1
Trip IN1>2
Trip IN1>3
Trip IN1>4
Trip ISEF>1
Trip ISEF>2
Trip ISEF>3
Trip ISEF>4
Trip Thermal
Trip NVD 1
Trip NVD 2
