Appendix B - Settings and Signals
P54A/B/C/E
B8
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Trip I2>1
Trip V< 1
Trip V< 2
Trip V< A
Trip V< B
Trip V< C
Trip V> 1
Trip V> 2
Trip V> A
Trip V> B
Trip V> C
Pred. OST
OST
Trip I2>2
Trip I2>3
Trip I2>4
[Binary Flag (32) Indexed String]
Displays the status of the second 32 trip signals.
Fault Alarms 01 0C
CB Fail 1
CB Fail 2
A/R Trip 1
A/R Trip 2
A/R Trip 3
A/R Trip 4
A/R Trip 5
VTS
PSB
CB2 Fail 1
CB2 Fail 2
CTS1
CTS2
Remote CTS
[Binary Flag (32) Indexed String]
Displays the status of the fault alarm signals.
Fault Time 01 0D
Fault Time
[IEC870 Time & Date]
Displays fault time and date.
Active Group 01 0E
Active Group
[Unsigned Integer (16 bits)]
Displays active setting group
System Frequency 01 0F
System Frequency
[Courier Number (frequency)]
Displays the system frequency
Fault Duration 01 10
Fault Duration
[Courier Number (time-seconds)]
Displays time from the start or trip until the undercurrent elements indicate the CB is open
CB Operate Time 01 11
CB Operate Time
[Courier Number (time-seconds)]
Displays time from protection trip to undercurrent elements indicating the CB is open
Relay Trip Time 01 12
Relay Trip Time
[Courier Number (time-seconds)]
Displays time from protection start to protection trip
Fault Location 01 13
Fault Location
[Courier Number (metres)]
Displays fault location in metres.
Fault Location 01 14
Fault Location
[Courier Number (miles)]
Displays fault location in miles.
Fault Location 01 15
Fault Location
[Courier Number (impedance)]
Displays fault location in ohms.
