P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B9
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Fault Location 01 16
Fault Location
[Courier Number (percentage)]
Displays fault location in percentage.
Start Elements 3 01 1A
V1>1 Cmp Start
V1>2 Cmp Start
Start I>>Diff
Start IN>NDiff
StubBus Start
[Binary Flag (32) Indexed String]
Displays the status of the third 32 start signals.
Trip Elements(3) 01 1C
V1>1 Cmp Trip
V1>2 Cmp Trip
Trip I>>Diff
Trip IN Diff
Intertrp IN Diff
[Binary Flag (32) Indexed String]
Displays the status of the third 32 trip signals.
IA Angle Pre Flt 01 20
IA Angle Pre Flt
[Courier Number (current)]
Measured parameter
IA Angle Pre Flt 01 21
IA Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
IB Angle Pre Flt 01 22
IB Angle Pre Flt
[Courier Number (current)]
Measured parameter
IB Angle Pre Flt 01 23
IB Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
IC Angle Pre Flt 01 24
IC Angle Pre Flt
[Courier Number (current)]
Measured parameter
IC Angle Pre Flt 01 25
IC Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
IN Angle Pre Flt 01 26
IN Angle Pre Flt
[Courier Number (current)]
Measured parameter
IN Angle Pre Flt 01 27
IN Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
IM Angle Pre Flt 01 28
IM Angle Pre Flt
[Courier Number (current)]
Measured parameter
IM Angle Pre Flt 01 29
IM Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
VA Pre Flt 01 30
VA Pre Flt
[Courier Number (voltage)]
Measured parameter
VA Angle Pre Flt 01 31
VA Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
VB Pre Flt 01 32
VB Pre Flt
[Courier Number (voltage)]
Measured parameter
VB Angle Pre Flt 01 33
VB Angle Pre Flt
[Courier Number (degrees)]
Measured parameter
VC Pre Flt
01
34
VC Pre Flt
