P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B21
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
MEASUREMENTS 4
05
00
This column contains measurement parameters
Ch 1 L-R1 Prop Dly 05 01
Ch 1 L-R1 Prop Dly
[Courier Number (time-seconds)]
Channel 1 propagation time is displayed in seconds. These times are the ones calculated with asynchronous sampling (some times called
“ping pong” method).
Ch 2 L-R1 Prop Dly 05 02
Ch 2 L-R1 Prop Dly
[Courier Number (time-seconds)]
Same as for channel 1
Channel 1 Status 05 07
Rx
Tx
Local GPS
Remote GPS
Mux Clk F Error
Signal Lost
Path Yellow
Mismatch RxN
Timeout
Message Level
Passthrough
H/W B to J mode
Max PropDelay
Max Tx-RxTime
[Binary Flag (11) & Indexed String]
‘Channel Status 1’ is a diagnostics flag associated with Channel 1 condition. See Channel 1 DDB descriptions
Channel 2 Status 05 08
Rx
Tx
Local GPS
Remote GPS
Mux Clk F Error
Signal Lost
Path Yellow
Mismatch RxN
Timeout
Message Level
Passthrough
H/W B to J mode
Max PropDelay
Max Tx-RxTime
[Binary Flag (11) & Indexed String]
‘Channel Status 2’ is a diagnostics flag associated with Channel 2 condition. See Channel 2 DDB descriptions
IM64 Rx Status 05 09
IM64 Rx Status
[Binary Flag (32) & Indexed String]
‘IM64 Rx Status’ is a 32 bit word that displays the status of received commands as 1 or 0.
IM64 Rx Status 2 05 0A
IM64 Rx Status 2
[Binary Flag (8) & Indexed String]
‘IM64 Rx Status 2’ is a 8 bit word that displays the status of received commands as 1 or 0.
STATISTICS
05
10
STATS RESET ON
05
11
Date/Time 05 12
Date/Time
[IEC870 Time & Date]
Displays the time and date of last statistics reset.
Ch1 No.Vald Mess 05 13
Ch1 No.Vald Mess
[Unsigned Integer (32 bits)]
Displays the number of received valid messages over channel 1 since last statistics reset.
Ch1 No.Err Mess 05 14
Ch1 No.Err Mess
[Unsigned Integer (32 bits)]
Displays the number of received errored messages over channel 1 since last statistics reset. The number of errored messages complies with
