Appendix B - Settings and Signals
P54A/B/C/E
B22
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
ITU- G8.21 and detailed in following cells
Ch1 No.Errored s 05 15
Ch1 No.Errored s
[Unsigned Integer (32 bits)]
Displays the number of seconds containing 1 or more errored or lost messages over channel 1
Ch1 No.Sev Err s 05 16
Ch1 No.Sev Err s
[Unsigned Integer (32 bits)]
Displays the number of seconds containing 31 or more errored or lost messages over channel 1. Any severely errored seconds are ignored
when working out the minutes intervals
Ch1 No.Dgraded m 05 17
Ch1 No.Dgraded m
[Unsigned Integer (32 bits)]
Displays the number of minutes containing 2 or more errored or lost messages over channel 1
Ch2 No.Vald Mess 05 18
Ch2 No.Vald Mess
[Unsigned Integer (32 bits)]
Same as for channel 1
Ch2 No.Err Mess 05 19
Ch2 No.Err Mess
[Unsigned Integer (32 bits)]
Same as for channel 1
Ch2 No.Errored s 05 1A
Ch2 No.Errored s
[Unsigned Integer (32 bits)]
Same as for channel 1
Ch2 No.Sev Err s 05 1B
Ch2 No.Sev Err s
[Unsigned Integer (32 bits)]
Same as for channel 1
Ch2 No.Dgraded m 05 1C
Ch2 No.Dgraded m
[Unsigned Integer (32 bits)]
Same as for channel 1
MaxCh1 PropDelay 05 26
MaxCh1 PropDelay
[Courier Number (time-seconds)]
Displays the maximum value of the channel 1 overall propagation delay divided by 2 when the protection communications are enabled.
MaxCh2 PropDelay 05 27
MaxCh2 PropDelay
[Courier Number (time-seconds)]
Same as for channel 1
Clear Statistics 05 30 No
No
Yes
[Indexed String]
The error statistics are automatically cleared on power-up. They can also be cleared using the Clear Statistics setting in Measurements
column of the menu.
Ch1 L-R2 PropDly 05 31
Ch1 L-R2 PropDly
[Courier Number (time-seconds)]
Channel 1 propagation time is displayed in seconds. These times are the ones calculated with asynchronous sampling (some times called
“ping pong” method).
Ch2 L-R2 PropDly 05 32
Ch2 L-R2 PropDly
[Courier Number (time-seconds)]
Same as for channel 1
Ch1 L-R3 PropDly 05 33
Ch1 L-R3 PropDly
[Courier Number (time-seconds)]
Channel 1 propagation time is displayed in seconds. These times are the ones calculated with asynchronous sampling (some times called
“ping pong” method).
Ch2 L-R3 PropDly 05 34
Ch2 L-R3 PropDly
[Courier Number (time-seconds)]
Same as for channel 1
Ch1 L-R4 PropDly 05 35
Ch1 L-R4 PropDly
[Courier Number (time-seconds)]
Channel 1 propagation time is displayed in seconds. These times are the ones calculated with asynchronous sampling (some times called
“ping pong” method).
Ch2 L-R4 PropDly 05 36
Ch2 L-R4 PropDly
[Courier Number (time-seconds)]
Same as for channel 1
Ch1 L-R5 PropDly 05 37
Ch1 L-R5 PropDly
[Courier Number (time-seconds)]
