GE P54E - CB CONDITION

P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B23
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Channel 1 propagation time is displayed in seconds. These times are the ones calculated with asynchronous sampling (some times called
“ping pong” method).
Ch2 L-R5 PropDly 05 38
Ch2 L-R5 PropDly
[Courier Number (time-seconds)]
Same as for channel 1
Ch1 L - R1 Lost Msgs 05 39
Ch1 L - R1 Lost Msgs
[Unsigned Integer (32 bits)]
Ch2 L - R1 Lost Msgs 05 3A
Ch2 L - R1 Lost Msgs
[Unsigned Integer (32 bits)]
Ch1 L - R2 Lost Msgs 05 3B
Ch1 L - R2 Lost Msgs
[Unsigned Integer (32 bits)]
Ch2 L - R2 Lost Msgs 05 3C
Ch2 L - R2 Lost Msgs
[Unsigned Integer (32 bits)]
Ch1 L - R3 Lost Msgs 05 3D
Ch1 L - R3 Lost Msgs
[Unsigned Integer (32 bits)]
Ch2 L - R3 Lost Msgs 05 3E
Ch2 L - R3 Lost Msgs
[Unsigned Integer (32 bits)]
Ch1 L-R4 Lost Msgs 05 3F
Ch1 L-R4 Lost Msgs
[Unsigned Integer (32 bits)]
Ch2 L-R4 Lost Msgs 05 40
Ch2 L-R4 Lost Msgs
[Unsigned Integer (32 bits)]
Ch1 L- R5 Lost Msgs 05 41
Ch1 L- R5 Lost Msgs
[Unsigned Integer (32 bits)]
Ch2 L- R5 Lost Msgs 05 42
Ch2 L- R5 Lost Msgs
[Unsigned Integer (32 bits)]
CB CONDITION
06
00
This column contains CB Condition Monitoring Measured Parameters
CB A Operations 06 02 0
CB A Operations
[Unsigned Integer (16 bits)]
Displays the total number of A phase trips issued by the IED
CB B Operations 06 03 0
CB B Operations
[Unsigned Integer (16 bits)]
Displays the total number of B phase trips issued by the IED
CB C Operations 06 04 0
CB C Operations
[Unsigned Integer (16 bits)]
Displays the total number of C phase trips issued by the IED
Total IA Broken 06 05 0
Total IA Broken
[Courier Number (current)]
Displays the total fault current interrupted by the IED for the A phase.
Total IB Broken 06 06 0
Total IB Broken
[Courier Number (current)]
Displays the total fault current interrupted by the IED for the B phase.
Total IC Broken 06 07 0
Total IC Broken
[Courier Number (current)]
Displays the total fault current interrupted by the IED for the C phase.
CB Operate Time 06 08 0
CB Operate Time
[Courier Number (time-seconds)]
Displays the calculated CB operating time.
Reset CB Data
06
09
No
No
