GE P54E - CB CONTROL

Appendix B - Settings and Signals
P54A/B/C/E
B24
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Yes
[Indexed String]
Reset the CB condition counters.
CB Monitoring 06 10
I^ Maint Alarm
I^ Lockout Alarm
CB OPs Maint
CB OPs Lock
CB Time Maint
CB Time Lockout
Fault Freq Lock
I^ Maint Alarm
I^ Lockout Alarm
CB2 OPs Maint
CB2 OPs Lock
CB2 Time Maint
CB2 Time Lockout
Fault Freq Lock
[Binary Flag (14) & Indexed String]
Displays the status of the CB Condition monitoring alarms
CB CONTROL
07
00
This column controls the circuit Breaker Control configuration
CB Control by 07 01 Disabled
Disabled
Local
Remote
Local+Remote
Opto
Opto+local
Opto+Remote
Opto+Rem+local
[Indexed String]
Selects the type of circuit breaker control to be used
Close Pulse Time 07 02 0.5
From 0.1 to 50 in steps of 0.01
[Courier Number (time-seconds)]
Defines the duration of the close pulse within which CB should close when close command is issued. If CB fails to close after elapse of this
time, CB close fail alarm is set.
Trip Pulse Time 07 03 0.5
From 0.1 to 50 in steps of 0.01
[Courier Number (time-seconds)]
Defines the duration of the trip pulse within which CB should trip when manual or protection trip command is issued. If CB does not trip
within set Trip Pulse Time, CB failed to trip alarm is set.
Man Close Delay 07 05 10
From 0.01 to 600 in steps of 0.01
[Courier Number (time-seconds)]
This defines the delay time before the close pulse is executed.
CB Healthy Time 07 06 5
From 0.01 to 9999 in steps of 0.01
[Courier Number (time-seconds)]
Settable time delay for manual closure with this circuit breaker check. If the circuit breaker does not indicate a healthy condition in this time
period following a close command then the IED will lockout and alarm. CB Healthy is required for manual and auto reclosure.
Check Sync Time 07 07 5
From 0.01 to 9999 in steps of 0.01
[Courier Number (time-seconds)]
A user settable time delay is included for manual closure with System Check Synchronizing. If the System Check Synchronizing criteria are
not satisfied in this time period following a close command the IED will lockout and alarm.
CB mon LO reset 07 08 No
No
Yes
[Indexed String]
Command to reset the CB monitoring Lockout Alarm
Rst CB mon LO by 07 09 CB Close
User Interface
CB Close
[Indexed String]
This setting is used to decide preferred option to reset a lockout condition caused by CB monitoring conditions either by a manual circuit
breaker close command or via the user interface.
CB mon LO RstDly 07 0A 5
From 0.1 to 600 in steps of 0.01
[Courier Number (time-seconds)]
