P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B25
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
If Rst CB mon LO by is set to CB close then CB mon LO RstDly timer allows reset of CB lockout state after set time delay
Autoreclose Mode 07 0B No Operation
No Operation
In Service
Out of Service
[Indexed String]
Command to changes state of Auto-Reclose, In Service or Out of Service
AR Status 07 0E
Out of Service
In Service
[Indexed String]
Status of the Auto Reclose - In Service / Out of service
CB Status Input 07 11 52B 1 pole
None
52A 3 pole
52B 3 pole
52A & 52B 3 pole
52A 1 pole
52B 1 pole
52A & 52B 1 pole
[Indexed String]
Setting to define the type of circuit breaker contacts that will be used for the circuit breaker control logic. Form A contacts match the status
of the circuit breaker primary contacts, form B are opposite to the breaker status.
When 1 pole is selected, individual contacts must be assigned in the Programmable Scheme Logic for phase A, phase B, and phase C. Setting
3 pole means that only a single contact is used, common to all 3 poles.
CB Status Time 07 7F 5
From 0.1 to 5 in steps of 0.01
[Courier Number (time-seconds)]
Under healthy conditions the circuit breaker auxiliary contacts will be in opposite states. Should both sets of contacts be open or closed, it
indicates that either the contacts, or the wiring, or the circuit breaker are defective and an alarm will be issued after CB Status Time delay.
The time delay is set to avoid unwanted operation during normal switching duties.
Reset AROK Ind 07 82 No
No
Yes
[Indexed String]
If Res AROK by UI is set to Enabled, this command provides a pulse to reset the successful AR indication for both CB's
Reset CB LO 07 83 No
No
Yes
[Indexed String]
If Res LO by UI is set to Enabled, this command provides a pulse to reset the lockout for CB.
Note: This requires the condition that caused the lockout to have been cleared.
CB Total Shots 07 85
CB Total Shots
[Unsigned Integer (16 bits)]
Indicates the total number of CB reclosures
CB SUCC SPAR 07 86
CB SUCC SPAR
[Unsigned Integer (16 bits)]
Indicates the total number of CB successful 1 pole reclosures
CB SUCC3PARShot1 07 87
CB SUCC3PARShot1
[Unsigned Integer (16 bits)]
Indicates the total number of CB successful 3 pole reclosures at 1st shot
CB SUCC3PARShot2 07 88
CB SUCC3PARShot2
[Unsigned Integer (16 bits)]
Indicates the total number of CB successful 3 pole reclosures at 2nd shot
CB SUCC3PARShot3 07 89
CB SUCC3PARShot3
[Unsigned Integer (16 bits)]
Indicates the total number of CB successful 3 pole reclosures at 3rd shot
CB SUCC3PARShot4 07 8A
CB SUCC3PARShot4
[Unsigned Integer (16 bits)]
Indicates the total number of CB successful 3 pole reclosures at 4th shot
CB Failed Shots 07 8B
CB Failed Shots
[Unsigned Integer (16 bits)]
Indicates the total number of CB failed reclose cycles
Reset CB Shots 07 8C No
No
Yes
[Indexed String]
