Appendix B - Settings and Signals
P54A/B/C/E
B120
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Ch 2 TX Prop Dly
IA
IB
IC
IN
IN Sensitive
VA
VB
VC
V Checksync
IM
IA2
IB2
IC2
IN2
V Checksync2
IA Differential
IB Differential
IC Differential
IN Differential
Max I Bias
Max Ih(2)
Ch 1 Prop Delay
Ch 2 Prop Delay
Ch 1 TX Prop Dly
Ch 2 TX Prop Dly
VN Measured
[Indexed String]
Selects any available analogue input to be assigned to this channel (including derived IN residual current).
MEASURE'T SETUP
0D
00
This column contains settings for the measurement setup
Default Display 0D 01 Description
3Ph + N Current
3Ph Voltage
Power
Date and Time
Description
Plant Reference
Frequency
Access Level
[Indexed String]
This setting can be used to select the default display from a range of options, note that it is also possible to view the other default displays
whilst at the default level using the left and right cursor keys. However once the 15 minute timeout elapses the default display will revert
to that selected by this setting.
Default Display 0D 01 Description
3Ph + N Current
3Ph Voltage
Power
Date and Time
Description
Plant Reference
Frequency
Access Level
[Indexed String]
This setting can be used to select the default display from a range of options, note that it is also possible to view the other default displays
whilst at the default level using the left and right cursor keys. However once the 15 minute timeout elapses the default display will revert
to that selected by this setting.
Local Values 0D 02 Primary
Primary
Secondary
[Indexed String]
This setting controls whether measured values via the front panel user interface and the front courier port are displayed as primary or
secondary quantities.
Remote Values
0D
03
Primary
Primary
